IMI Zeparo ZTVI DN20 Turnable Deaerator - 3/4" BSP F (30302070501)

Media:

Non-aggressive and non-toxic system media.
Addition of antifreeze agent up to 50%.

Pressure:

Max. admissible pressure, PS: 10 bar
Min. admissible pressure, PSmin: 0 bar

Temperature:

Max. admissible temperature, TS: 110 °C
Min. admissible temperature, TSmin: -10 °C

Material:

Body: Brass
Inserts: PP 30% GF (plastic)
Clip: springsteel EN 10270-1 SH

Transportation and storage:

In frostless, dry places.

Thermal insulation:

Insulation: Expanded polypropylene (EPP), anthracite.
Insulation value approx. 0.035 W/mk.
Fire rating B2 to DIN 4102 and E in acc. to EN 13501-1.
Max. temperature: 110 °C.
Min. temperature: 6-8 °C (above dew point).
